Surgical Face Mask Production Line(Fully Automatic Folding All-in-One)

Surgical Face Mask Production Line

This surgical face mask production line is applied for the automatic forming of folding masks. This is multifunctional machinery that carries out raw material roll unwinding, roller driving, feeding nose clip, welding and wrapping nose clip, (pneumatic valve hole optional), (printing optional), welding earloop 1, welding earloop 2, folding, edge welding, cutting, and finished product discharging. All these processes are fully automated, giving the production line the advantages of stable performance, high output capacity, low defect rate, and easy operation.

Technical Parameters
Dimension 8000mm(L) X1400mm(W) X1600mm(H)
Color International standard warm grey 1C
Weight ≤5000kg, ground weight capacity ≤500kg/m2
Working power Equipment 220VAC±5%; 50HZ; rated power 17kW
Working air pressure Compressed air pressure 0.5-0.8MPa; compressed air flux 300L/min(stable flux guaranteed; oil and water have to be filtered)
Production efficiency 1800-2500PCS/H(based on 20 hours each day, daily capacity about 36,000-50,000 pieces)
Qualification ratio 99%(excluding unqualified incoming materials, improper operation by employees)
Equipment failure ratio ≤2%(equipment failure itself)
Operating environment Temperature 10一35℃; humidity: 5-35%HR No flammable, corrosive gas, no dust (cleanliness no less than 100,000 grade)
